Custom modular systems crafted for reliability

Modular Switchboard Systems

From Eaton xEnergy to bespoke MCCs, our modular switchboard systems deliver flexible, front/rear accessible, form‑compliant solutions up to 7,100 A.

Request a Quote

Download Datasheet

Engineered for uptime and versatility

Key Features at a Glance

Fixed, plug‑in, removable, and withdrawable section options

IP55-rated rugged enclosures

Compliance with AS/NZS 61439 and IEC standards

Busbar ratings up to 7,100 A, short-circuit rating to 105 kA

Internal separation up to Form 4b

Scalable, certified, and built to last

Product Overview

Pro‑Tech’s Modular Switchboard Systems—including Eaton xEnergy, Legrand XL3, or NHP Cubic platforms—are built in‑house to offer scalable, code‑compliant power and motor control solutions. Our systems are designed to support front and rear access and deliver maximum uptime and minimal downtime.

Technical Specifications

Precision-engineered to code

Specification	Details
Rated Current	Up to 7,100 A (dependent on platform)
IP Rating	IP55 standard, up to IP65 availables
Internal Separation	Form 1 to Form 4b
Short-Circuit Withstand	Up to 105 kA/1s
Standards	AS/NZS 61439, IEC 60439/61439 certified
Section Types	Fixed, plug‑in feeder, withdrawable, MCC
Busbar Systems	Up to 7,100 A copper/aluminium

Flexible for diverse sectors

Applications & Use Cases

Main switchboards and switchgear in commercial and industrial sites

Motor Control Centres (MCCs) for pumps, fans, conveyors

Data centres, hospitals, mining and utilities

Expandable modular systems for future upgrades

High-current distribution setups up to 7,100 A

Tailored to your project

Available Variants / Options

Platform choices: Eaton xEnergy, Legrand XL3, NHP Cubic

Section forms: fixed, plug-in, withdrawable (XW, XR, etc.)

IP rating upgrade (IP55 → IP65)

Front/back access configurations

Engineered to certified specs

Industry Compliance & Standards

Design-verified to AS/NZS 61439 & IEC 60439/61439

Internal separation to Form 4b

IP55+ enclosure protection

Arc fault containment zones and busbar pressure vent

1 +

Projects Delivered

1 +

Switchboards Built

1 +

On-Site Commissionings

1 +

Years of Expertise

Here’s what clients ask most

Frequently Asked Questions (FAQs)

What platforms are offered?

We build on Eaton xEnergy, Legrand XL3, NHP Cubic—all design-verified to AS/NZS 61439.

Can the switchboard include withdrawable sections?

Yes—we offer fixed, plug-in, and withdrawn modules (XW/XR types) for maintenance safety.

What's the maximum current rating?

Up to 7,100 A with busbars and sections suited to heavy industrial use.

Is it weather-rated?

Standard is IP55, with IP65 attainable via enhanced enclosure design.

How is compliance ensured?

All systems are factory tested and-certified to AS/NZS 61439 and IEC standards—fully compliant.

Ready for a reliable modular solution?

Get a custom Modular Switchboard System—fully compliant, scalable, and built to perform.

Request a Custom Quote

Download Specification Guide
